Pneumatic Rice Husker

  • Pneumatic Rice Husker

Short Description:

Pneumatic Rice Husker can remove rice husk efficiently.


Product Detail

Production Case

 Pneumatic Rice Husker Characteristic:

◆ Automatic controls the motion sequence of equipments to realize tightening rollers when paddy feeding and loosening it when no feeding,it is convenience in operation.
◆ Lineal control of tightening pressure between rolls with barometer,digital-regulated display of feeding volume,it is easy and simple in adjustment.
◆ Use-so vibration feeding,loog feeding chute enable,can get big capacity,low broken,high efficiency.
◆ Use synchronous belt transmission and no gear box,low noise and none oil leak ,be good for rice cleanness.
◆ Firstly witnesses double-supported prop structure with smooth transmission and stable performance
◆ Use vertical air suction duct when separating paddy shell.

Pneumatic Rice Husker Technical parameter:

Model

MLGQ25B

MLGQ36

MLGQ51

Capacity

3-5t/h

4-6 t/h

6-10 t/h

Power

7.5kW

11 kW

15 kW

Wind Volume

3400-3700 m3/h

4000-4500m3/h

6800-7400m3/h

Rubber Roller Size(diameter×length)mm

254×254

225×356

254×508

Weight(kg)

700

1000

1300
